Cast iron Insert
CAST IRON Insert
Our extensive range of general turning grades and chipbreakers offers versatile solutions tailored to various insert shapes, sizes, and thicknesses. Each option is designed with the same objective: to enhance productivity and extend tool life in your turning applications.
HPMT Achieves +32% Longer Tool Life
Compared to Competitor
Case Study 1:
| Cutting Condition | |
|---|---|
| Operation | Facing, Roughing |
| Industry | General Machining |
| Workpiece Material | FC250 (Cast Iron, K) |
| Workpiece Hardness | 20-30 HRC |
| Workpiece Treatment | Machined |
| Tool Test Condition | ||
|---|---|---|
| Tool Producer | Competitor T | HPMT |
| Insert | CNMA120412 | CNMA120412 |
| Chipbreaker | Flat | Flat |
| Grade | T515 | HCK2000 |
| Cooling | Dry | Dry |
| Cutting Speed (m/min) | 231 - 490 | 231 - 490 |
| Feed (mm/rev) | 0.3 | 0.3 |
| Depth of Cut ap (mm) | 1 | 1 |
| Machined Diameter (mm) | 49 - 104 | 49 - 104 |
| Machining Length (mm) | -/- | -/- |
| Tool Life (pcs/edge) | 60-70 | 90-100 |
